PEAI-9910 Series

Edge AI Systems with 12^th/13^th/14^th Gen Intel^® Core^™ up to 65W Supporting NVIDIA RTX 4060

Features

Supporting NVIDIA RTX 4060 GPU Card
Supports 12^th/13^th/14^th Gen Intel^® Core^™ LGA1700 processors, TDP support up to 65W
Supports up to two 262pin SODIMM up 64GB DDR5,Dual Channel DDR5 4800 MHz
Additional PCIe slots and M.2 socket for expansion
High speed dual 5GbE Ethernet based on Marvell LAN chip, high bandwidth I/O interface

Video

Play Video

Description

The PEAI-9910 series is built on Intel^® desktop R680E chipset and take advantage of 13^th/14^th Generation Intel^® Core™ i3/i5/i7/i9 processors. Supports NVIDIA^® high performance GPU card. The PEAI-9910 series is an ideal platform with rich I/O and high resolution for edge AI computing and factory automation applications.

Specification

System
System
M/B	Proprietary ROBO-9910G2AR-A
CPU	12^{th /}13^th /14^th Gen Intel^®Core™ LGA1700 Socket Processors, TDP support up to 65W
Chipset	Intel^® R680E
BIOS	AMI uEFI BIOS
Memory	Supports up to two 262pin SODIMM up 64GB DDR5 Dual Channel DDR5 4800 MHz
Storage	Supports 2x 2.5inch SSD or 2x 3.5inch HDD Draw Box Supports RAID 0, 1
Watchdog Timer	Programmable watchdog timer, time out period from 0.5 sec to 254.5 secs.
Hardware Monitoring	System monitor(Voltage,Fan Speed and Temperature)
Expansion Interface	1x PCIe x16 Gen5 slot 1x PCIe x4 Gen4 slot Supports 1x M.2 Type M 2280 with PCIex4 signal

External I/O
External I/O
Audio	Line-Out & Mic-In
Display	1x HDMI^® 2.0, supports up to 4096 x 2160 @ 60 Hz 1x DP 1.2, supports up to 4096 x 2160 @ 60 Hz
Ethernet	2x 5 Gigabit Ethernet ports
USB	2x USB 3.2(Gen2) ports 2x USB 3.2(Gen1) ports
GPIO	1x 8-bit Digital I/O port

Power Supply Unit
Power Supply Unit
Power Input	AC to DC, AC 100~240V
Power Supply	PEAI-9910 650W

Environmental
Environmental
Operation Temperature	0°C ~ 40°C
Storage Temperature	-20°C ~ 80°C
OS	Win11 IOT Enterprise LTSC

Specifications
Mechanical
Dimension	440mm(L)182mm(W)280mm(H)
Weight	15 Kg

Ordering Guide

Ordering Guide
TBD	Please contact Portwell for more information.
